Theory Of Machine (Tom) Handwritten Notes By Ashish Sir | Mechanical Engineering (Copy)

Description

Master the complexities of Theory of Machines with Ashish Sir’s detailed handwritten notes, tailored specifically for Mechanical Engineering students. These notes cover essential concepts, mechanisms, and principles with clear explanations, diagrams, and real-world examples. Designed for easy understanding and exam preparation, the notes ensure a solid grasp of TOM fundamentals.

Included Chapters:

1. Mechanisms and Machines: Links, Pairs, Chains, Structure, Mechanism, Machine, Equivalent linkage, Degrees of freedom, Gruebler’s & Kutzback’s criterion, Inversions of four bar chain, Mechanism with lower pairs Pantograph, Straight line motion mechanisms, Davis and Ackermann’s steering mechanisms, Hooke’s joint, Numerical problems based on above topics..
2. Gears: Classification of gears, Helical, Spiral, Bevel, Worm and Spur Gear, Spur Gear Terminology, Law of gearing, Tooth profiles, , velocity of sliding, Path of contact, Arc of contact, Contact Ratio, Interference and Undercutting, , Conjugate action, Numerical problems based on above topics
3. Gear Trains : Simple, compound, reverted and epi cyclic gear trains . Velocity ratio and torque calculation in gear trains
4. Cams: Classification of Cams and Followers, Radial Cam Terminology, Analysis of Follower motion (uniform, modified uniform, simple harmonic, parabolic, cycloidal), Pressure Angle, Radius of Curvature, Cam Profile for radial and offset followers Synthesis of Cam Profile by Graphical Approach, Cams with Specified Contours.
5. Gyroscope: Gyroscopic Action in Machines, Angular Velocity and Acceleration, Gyroscopic torque/ couple, Gyroscopic effect on Naval Ships, Stability of Two and Four Wheel Vehicles, Rigid disc at an angle fixed to a rotating shaft.
6. ​Belt Rope & Chain Drive : Types of Belts, Velocity ratio of a belt drive, Slip in belts, Length of open belt and crossed belt, Limiting ratio of belt-Tensions, Power transmitted by a belt, Centrifugal tension, Maximum tension in a belt, Condition for maximum power transmitted, Initial tension in a belt, Creep in belt, Applications of V-Belt, Rope and Chain drives.

Before Purchase Please Go through Our Sample Copy: Click Here

Before purchasing, we encourage you to review our sample copies to evaluate the content quality and handwriting style. Please note, there is no return policy, so make sure the material meets your expectations by checking the samples first. Ideal for exam preparation and a solid foundation in SOM topics!
